Pipe Railing Fittings Adjustable Angle Two Socket Cross

Description:

Adjustable Angle Two Socket Cross is a Pipe Railing Fittings that can adjust the angle between uprights and railings. It has two types, namely 156 Two Socket Cross 0-11 Degrees and 256Z Middle Rail Slope Cross 11-29 Degrees. Its function is to add a rail to the Railing System. The materials of Adjustable Angle Two Socket Cross are mainly ductile iron, malleable steel, aluminum alloy, and stainless steel. It can choose a more suitable surface treatment method from galvanized, powder spraying, polishing, and sandblasting according to the material. HULK Metal has provided high-quality Pipe Railing Fittings to hundreds of customers all over the world. If you need, you can contact us at any time.



Parameters of Pipe Railing Fittings Adjustable Angle Two Socket Cross

NAMEPipe Railing Fittings Adjustable Angle Two Socket Cross
MATERIALMalleable Steel / Ductile Iron / Aluminum Alloy /   Stainless Steel
SURFACE TREATMENTGalvanized/Powder-coat/Customizable
PROCESSSand Casting /Investment Casting / Die Casting /   Tapping /Surface Treatment
CERTIFICATIONCE / TUV / SGS
COLORMetallic / Silver / Black / Customizable
TUBE SIZE(mm)Inches
B33.71"
C42.41 1/4"
D48.31 1/2"
OTHERCustomizable
OTHER SERVICE
BRANDINGCustomizable
PACKAGINGCarton & Wooden Pallet / Customizable
DELIVERYFOB / CFR / Customizable
AFTER SERVICEQuality Assurance Service


Features of Pipe Railing Fittings Adjustable Angle Two Socket Cross

  • 2 Steps to Complete the Installation:
    2 Steps to Complete the Installation:

    The Adjustable Angle Two Socket Cross was originally designed to facilitate users to add a slanted railing to the post of the guardrail system more quickly. This Pipe Railing Fitting only needs 2 steps to complete the installation. Step 1: Put the Adjustable Angle Two Socket Cross on the uprights, adjust the angle, and tighten the screws on the socket. Step 2: Insert the two pipes into the socket and tighten the screws on the socket. This completes the installation successfully.


  • Choose Malleable Steel or Ductile Iron?
    Choose Malleable Steel or Ductile Iron?

    Malleable steel KTH350-10 and ductile iron QT450-10 both have very good mechanical properties. In most environments, ductile iron will perform slightly better than malleable steel. We can simulate the customer's use environment for testing to meet customer requirements. Aluminum Pipe Railing Fittings not only have great performance, but are also lighter. Many customers now choose to use aluminum alloy instead of ductile iron and malleable steel.



  • Galvanized Or Powder Coated?
    Galvanized Or Powder Coated?

    The galvanized Adjustable Angle Two Socket Cross has a very good metal texture and anti-corrosion resistance. Powder coated Pipe Railing Fittings have a better looking color, and when we choose a better powder, we can achieve better protection performance. Of course, choosing a better powder also means that the cost will increase. The thickness of both coatings is about 0.1mm. Customers can choose a more suitable surface treatment method according to their needs.



  • The Quality Can Be Assured:
    The Quality Can Be Assured:

    HULK Metal's factories are ISO 9001 certified. Our quality inspectors have worked for more than 15 years. They will formulate strict testing standards and procedures according to customer requirements. We have produced Pipe Railing Fittings for customers that can pass CE, TUV, and SGS testing. If you need to buy an Adjustable Angle Two Socket Cross, you can rest assured to place the order to us.


  • Professional Service:
    Professional Service:

    HULK Metal will provide high-quality and comprehensive services for every buyer of structural pipe fittings. We will fully understand the needs of each customer and formulate a complete production solution. Provide more thoughtful packaging, shipping, and quality assurance services. We will treat every order seriously and rigorously.
