Structural Pipe Fittings Side Support (Vertical Base)144

Description:

144 Vertical Base Railing Side Support is fittings that can fix a safety railing system on the wall, the outside of the stairs, and the inside or outside of the balcony. It can be fixed with two bolts (the hole on the socket side can only allow 40mm bolts to pass through). Galvanized Vertical Base Railing Side Support has good rust resistance and a beautiful appearance. Both ductile iron and malleable Structural Pipe Fittings have good mechanical properties. HULK Metal has a complete set of molds and a complete service team to provide excellent manufacturing services. If you need to purchase Structural Pipe Fittings, contact us.

Parameters of Structural Pipe Fittings Side Support(Vertical Base)144

NAMEStructural Pipe Fittings Side Support(Vertical Base)144
MATERIALMalleable Steel / Ductile Iron / Aluminum Alloy /   Stainless Steel
SURFACE TREATMENTGalvanized/Powder-coat/Customizable
PROCESSSand Casting /Investment Casting / Die Casting /   Tapping /Surface Treatment
CERTIFICATIONCE / TUV / SGS
COLORMetallic / Silver / Black / Customizable
TUBE SIZE(mm)Inches
B33.71"
C42.41 1/4"
D48.31 1/2"
OTHERCustomizable
OTHER SERVICE
BRANDINGCustomizable
PACKAGINGCarton & Wooden Pallet / Customizable
DELIVERYFOB / CFR / Customizable
AFTER SERVICEQuality Assurance Service

Features of Safety Structural Pipe Fittings Side Support(Vertical Base)144

  • Faster and Easier to Install:
    Faster and Easier to Install:

    When installing 144 Vertical Base Railing Side Support, we first drill holes in the wall and then use two bolts to fix it on the wall (the side near the socket is recommended to use hexagonal bolts for easy tightening). After fixing the Vertical Base Railing Side Support, we will insert the pipe into the socket and tighten the fastening screws to complete the installation.


  • Adapt to More Scenarios:
    Adapt to More Scenarios:

    144 Vertical Base Railing Side Support has a better appearance and rust resistance after galvanized or powder-coated treatment. Galvanized Vertical Base Railing Side Support can be used for outdoor safety railings systems such as stairs or balconies because it is more suitable for sunlight than powder-coated ones. Powder coating is more suitable for indoor scenes without direct sunlight.


  • Better Casting Performance and Higher Standards:
    Better Casting Performance and Higher Standards:

    144 Vertical Base Railing Side Support is a one-time molding using an advanced sand casting process, which has good casting performance. HULK Metal's factory will strictly implement the ISO 9001 quality management system and has manufactured the fittings of safety railing systems that can pass CE, TUV, and SGS certification for hundreds of customers and has become their long-term supplier. If you have an order, please feel free to contact us.


  • Provide Malleable Steel and Ductile Iron:
    Provide Malleable Steel and Ductile Iron:

    HULK Metal mainly produces 144 Vertical Base Railing Side Support made of malleable steel and ductile iron for customers because these two materials have a more comprehensive range of applications. We can provide OEM service of Stainless Steel and Aluminum Structural Pipe Fittings. After cost calculation, the cost of aluminum safety railing fittings is not much different from that of malleable steel and ductile iron. You can leave us a message if you have any needs.


  • More Comprehensive Services:
    More Comprehensive Services:

    HULK Metal has been manufacturing Structural Pipe Fittings for over 16 years. We have an experienced service team that can meet customers' service requirements and suitably solves problems. We develop unique service solutions for each buyer. If you have any needs, you can contact us at any time.
